Inductive Proximity Sensor LJ20A3-8-Z/AY 3Wire NC DC 6-36V PNP 200mA Proximity Switch

Name: Inductive Proximity Sensor LJ20A38ZAY 3Wire NC DC 636V PNP 200mA Proximity Switch
Brand: KAMPA
Price: 3.00 USD

Quality Inductive Proximity Sensor LJ20A3-8-Z/AY 3Wire NC DC 6-36V PNP 200mA Proximity Switch for sale

Model Number : LJ20A3-8-Z/AY

Place of Origin : Zhejiang, China

Brand Name : KAMPA

Usage : Magnetic Sensor

Theory : Inductance Sensor

Output : Switching Transducer

OEM : YES

Detection distance : 8mm + 10%

Set the distance : 0 - 7mm

Lag distance : The detection range below 10%

Standard test object : Iron 30*30*1mm

Frequency response : DC:0.5kHz AC:25Hz

supply voltage : DC type: DC12 - 24V (6-36V) AC: AC110 - 220V (36 - 250V)

Current consumption : Type N.P: 13mA, D: 0.8mA, A: 1.7mA

Output control : Type N.P: 300mA, D: 200mA, A: 400mA

Protection structure : IP67 (IEC)

Packaging Details : Standard export carton

Port : NingBo/SHANGHAI

Supply Ability : 20000 Piece/Pieces per Month

Price : $3.00 - $5.00/Pieces

Contact Now

LJ20A3-8-Z/BX NPN /NO/DC/proximity switch approach switch

model	LJ20A3-8-.
Product picture

size
Installation mode				Nonshielded
model	DC type	NPN	NO	LJ20A3-8-Z/BX
			NC	LJ20A3-8-Z/AX
			NO+NC	LJ20A3-8-Z/CX
		PNP	NO	LJ18A3-8-Z/BY
			NO	LJ20A3-8-Z/AY
			NO+NC	LJ20A3-8-Z/CY
		second line—an advisory post	NO	LJ20A3-8-Z/EX
			NC	LJ20A3-8-Z/DX
	AC	second line—an advisory post	NO	LJ20A3-8-J/EZ
			NC	LJ20A3-8-J/DZ
		Three line	NO+NC	LJ20A3-8-J/EDZ
Detection distance				8mm + 10%
Set the distance				0 - 7mm
Lag distance				The detection range below 10%
Object detection				Magnetic metal (non magnetic metal detection distance decreases)
Standard test object				Iron 30301mm
Frequency response				DC:0.5kHz AC:25Hz
supply voltage				DC type: DC12 - 24V (6-36V) pulse (P-P) below 10%, AC: AC110 - 220V (36 - 250V) 50/60Hz
Withstanding voltage				AC1000V 50/60Hz 1min charging part and the shell.
The influence of voltage				Within the rated supply voltage range 15% rated supply voltage of + 10% detection distance
Current consumption				Type N.P: 13mA, D: 0.8mA, A: 1.7mA
Output control				Type N.P: 300mA, D: 200mA, A: 400mA
Loop protection				Type N.P.D: reverse connection protection, surge absorption, load short-circuit protection, type A: surge absorption
The environment temperature and humidity				When the movement, save the -30 +65 C (ice, frost), action, save time: 35 - 95%RH
The influence of temperature				The temperature range of -30 DEG C - +65, +23 C, + 15% detection distance The temperature range of -25 DEG C - +60, +23 C, + 10% detection distance
Insulation resistance				The above 50M (DC500 megameter) charging part and the shell.
texture of material				Shell: nickel plated brass surface detection: ABS
Protection structure				IP67 (IEC)

Inductive Proximity Sensor LJ20A3-8-Z/AY 3Wire NC DC 6-36V PNP 200mA Proximity Switch

Packaging & Shipping

Company Information

Yueqing Kampa Electric Co.,Ltd. is Established in 1990.Has variety of goods ,such as Relay,Circuit breaker,Switches,Thermocouple,Thermostat,Temperature controller,Switch power supply,AVS,Heat sink,Heater,Distribution box,Junction box and so on.We are manufacturer and have ten years experience in Electrical industry.

Our Services

Inductive Proximity Sensor LJ20A3-8-Z/AY 3Wire NC DC 6-36V PNP 200mA Proximity Switch

A.Punctual delivery time:

We carry out your order into our well-organized production schedule, ensure your punctual delivery time.
Production report before your order packed.
Shipping notice and photos sent to you as soon as your order is shipped.
B.After sales service:
We Pay high Attention To Your Feed back after receive the goods.
We Provide 12 months warranty after goods arrive.
We Promise All Parts Available in lifetime use.
We Positively Revert Your Complain Within 48hours.
C.Professional Sales:
We value every Inquiry Sent To Us, Ensure Quick Competitive Offer.
We Cooperate With Customer To Bid Tenders. Provide all Necessary Documents.
We Are A Sales Team, With AllTechnical Support From Engineer Team.

Inductive Proximity Sensor LJ20A3-8-Z/AY 3Wire NC DC 6-36V PNP 200mA Proximity Switch Images
